| h(FE) Max. Current gain.: | 220 |
| h(FE) Min. Current gain.: | 120 |
| @I(C) (A) (Test Condition): | 2.0m |
| Mounting Style: | T |
| Package Style: | TO-92 |
| Military/High-Rel: | N |
| @I(C) (A) (Test Condition): | 100m |
| V(BR)CEO (V): | 30 |
| V(CE)sat Max. (V): | .65 |
| @I(C) (A) (Test Condition): | 2.0m |
| @V(CE) (V) (Test Condition): | 5.0 |
| @V(CE) (V) (Test Condition): | ± |
| @V(CE) (V) (Test Condition): | 5.0 |
| Absolute Max. Power Diss. (W): | 625m’ |
| h(fe) Min. SS Current gain.: | 125 |
| @I(C) (A) (Test Condition): | 10m |
| @V(CBO) (V) (Test Condition): | 20 |
| f(T) Min. (Hz) Transition Freq: | 360MÂ |
| @Freq. (Hz) (Test Condition): | 1.0k |
| I(C) Max. (A): | 100m |
| V(BR)CBO (V): | 30 |
| @I(B) (A) (Test Condition): | 5.0m |
| @V(CE) (V) (Test Condition): | 5.0 |
| Maximum Operating Temp (øC): | 150õ |
| I(CBO) Max. (A): | 100n |
