| Minimum Operating Temp (øC): | -45 |
| V(GT) Max.(V): | 2.5 |
| I(TSM) Max. (A): | 6.5k |
| # & Name of Quick-Connects: | 2G-2GR |
| @Temp. (øC) (Test Condition): | 125õ |
| V(DRM) Max. (V): | 1.0k |
| @Temp. (øC) (Test Condition): | 85# |
| Mounting Style: | T |
| Package Style: | MODULE-var |
| V(T) Max. (V): | 1.6 |
| I(GT) Max. (A): | 150m |
| Mounting Profile Code: | M:HL080HW038 |
| I(H) Max. (A) Holding Current: | 250m |
| V(RRM) Max. (V): | 1.0k |
| # & Name of Screw Terminals: | A-K-AK |
| I(T) Rated Maximum (A): | 180 |
| Maximum Operating Temp (øC): | 125õ |
| I(D) Max. (A) Leakage Current: | 30m |
| @I(T) (A) (Test Condition): | 559 |
