| @I(T) (A) (Test Condition): | 173 |
| @Temp. (øC) (Test Condition): | 85 |
| Maximum Operating Temp (øC): | 125õ |
| Minimum Operating Temp (øC): | -40 |
| I(T) Rated Maximum (A): | 55± |
| Thermal Resistance Junc-Case: | .25 |
| Mounting Profile Code: | N/A |
| dv/dt Min. (V/us): | 500 |
| Package Style: | TO-240AA |
| # & Name of Screw Terminals: | A-K-AK |
| I(GT) Max. (A): | 100m |
| # & Name of Quick-Connects: | 2G-2GR |
| V(GT) Max.(V): | 2.5 |
| Mounting Style: | T |
| I(D) Max. (A) Leakage Current: | 15m |
| I(H) Max. (A) Holding Current: | 200m |
| t(gt) Typ. (s): | 150ù |
| V(DRM) Max. (V): | 1.2k |
| I(TSM) Max. (A): | 1.4kß |
| V(RRM) Max. (V): | 1.2k |
| @ t(w) (s) (Test Condition): | 8.3m |
| V(T) Max. (V): | 1.4 |
| @Temp. (øC) (Test Condition): | 125õ |
