Price Per Quantity
| Output Circuit Type: | MOSFET |
| Output Type: | AC Output |
| Switching Mode: | Random |
| Form: | SPDT |
| Number of Channels: | 1 |
| Output Transistor Current (A): | .17 |
| Output Transistor Voltage (V): | 250 |
| Type of Input AC/DC: | DC Input |
| Min. On Current (Controlled): | 10m |
| Min. On Voltage (Controlled): | 0.9 |
| Overall Length (mm): | 9 |
| Overall Width (mm): | 6 |
| Overall Height (mm): | 3 |
| Minimum Operating Temp (øC): | -40 |
| Maximum Operating Temp (øC): | 85 |
| Maximum Isolation Voltage (V): | 2.5k |
| Package Style: | DIP |
| Mounting Profile Code: | N/A |
| Not at Breakdown Voltage | Ë |
