| Military/High-Rel: | N |
| V(BR)CEO (V): | 80 |
| V(BR)CBO (V): | 80 |
| I(C) Max. (A): | 500m |
| Absolute Max. Power Diss. (W): | 625m’ |
| Maximum Operating Temp (øC): | 150õ |
| I(CBO) Max. (A): | 100n |
| @V(CBO) (V) (Test Condition): | 80 |
| V(CE)sat Max. (V): | .40 |
| @I(C) (A) (Test Condition): | 100m |
| @I(B) (A) (Test Condition): | 5.0m |
| h(FE) Min. Current gain.: | 100 |
| h(FE) Max. Current gain.: | 300 |
| @I(C) (A) (Test Condition): | 1.0m |
| @V(CE) (V) (Test Condition): | 5.0 |
| f(T) Min. (Hz) Transition Freq: | 150M |
| @I(C) (A) (Test Condition): | 10m |
| @V(CE) (V) (Test Condition): | 5.0 |
| C(obo) (Max) (F): | 6.0 |
| @V(CB) (V) (Test Condition): | 5.0 |
| @Freq. (Hz) (Test Condition): | 1.0M |
| Package Style: | TO-92 |
| Mounting Style: | T |
| at V(GR) ó 0 | å |
