| h(FE) Max. Current gain.: | 250 |
| Mounting Style: | S |
| @Freq. (Hz) (Test Condition): | 500M |
| Package Style: | SOT-37var |
| @I(C) (A) (Test Condition): | 50m |
| Military/High-Rel: | N |
| @Freq. (Hz) (Test Condition): | 500M |
| @I(C) (A) (Test Condition): | 50m |
| V(BR)CEO (V): | 15 |
| Minimum Operating Temp (øC): | -65 |
| @I(C) (A) (Test Condition): | 50m |
| Power Gain Min. (dB): | 11 |
| @V(CE) (V) (Test Condition): | 10 |
| @V(CE) (V) (Test Condition): | 5.0 |
| @V(CE) (V) (Test Condition): | õ |
| Absolute Max. Power Diss. (W): | 2.5 |
| Semiconductor Material: | Silicon |
| @I(C) (A) (Test Condition): | 75m |
| @V(CE) (V) (Test Condition): | 10 |
| @V(CBO) (V) (Test Condition): | 15 |
| f(T) Min. (Hz) Transition Freq: | 5.0GÂ |
| I(C) Max. (A): | 200m |
| V(BR)CBO (V): | 30 |
| @V(CE) (V) (Test Condition): | 10 |
| Noise Figure Min. (dB): | 1.8Â |
| Maximum Operating Temp (øC): | 150õ |
| I(CBO) Max. (A): | 100u |
