Price Per Quantity
| Military/High-Rel: | N |
| Tech.: | Bipolar |
| Logic Funct.: | NOR |
| Output Config: | Open-Coll |
| Outp Transis. Ion Max.: | 600m |
| VOL Max.: | .7 |
| @Iol (A): | 300m |
| VOH Max.: | 80 |
| t(PLH) Maximum (S): | 500n |
| Input Logic Family: | C/PMOS;D/T |
| VIL Max. (V): | .8 |
| VIH Min. (V): | 2 |
| Nom. Supp (V): | 5 |
| P(D) Max. (W): | 1.5 |
| Minimum Operating Temp (øC): | -20 |
| Maximum Operating Temp (øC): | 85 |
| Package Style: | DIP |
| Mounting Style: | T |
| # Pins: | 8 |
| Not at Breakdown Voltage | É |
